MultiPlus-II 48V

$1,540.20 USD

Sale Sold out

Shipping calculated at checkout.

Victron Energy

SKU:PMP482505120

CE FCC NDAA RoHS UL Listed

Ships from Houston, TX. In-stock items ship within 1-2 business days.

Authorized Victron Energy dealer. Full manufacturer warranty.

Ordering multiple units? Request volume pricing

View full details

Need help designing a system?

Our engineers spec complete Victron power systems for your application: batteries, inverters, MPPT, and monitoring.

Talk to an Engineer

Technical Specifications

Continuous Power	3,000VA / 2,400W to 15,000VA / 12,000W (model dependent)
Peak Power	Up to 2x rated VA for 10 seconds
Battery Voltage	48V nominal (38-66V range)
Max Charge Current	35A to 200A (model dependent)
Transfer Time	<20 ms
AC Input Range	187-265 VAC (adjustable)

Peak Efficiency	94-96%
Communication	VE.Bus, Bluetooth (via dongle or GX)
Operating Temp	-40°C to +65°C
Weight	19 kg to 80 kg (model dependent)
Dimensions	Varies by model; 3kVA: 362 x 258 x 218 mm
Certifications	EN/IEC 62109-1, EN/IEC 60335-1

Combined inverter/charger with two AC outputs, PowerAssist, and full GX integration.

The Victron MultiPlus-II 48V is a multifunctional inverter/charger designed for off-grid, mobile, and energy storage systems. Available in 3,000VA to 15,000VA models, it delivers true sine wave output with automatic transfer switching in under 20 milliseconds. PowerControl and PowerAssist allow the system to supplement limited AC sources like generators or shore power by adding inverter power on demand.

Built-in VE.Bus communication enables parallel and three-phase configurations, managed through a Cerbo GX or other GX device. The adaptive charge algorithm supports lithium, AGM, and flooded battery chemistries with configurable charge profiles via VictronConnect. Dual AC outputs provide separate always-on and transfer-switched circuits for critical and non-critical loads.

Used in Alchemy off-grid power systems for primary AC conversion, generator integration, and grid-interactive backup.
