Talk to an EngineerTechnical Specifications
| Battery Capacity | 3072Wh |
|---|---|
| Battery Type | LiFePO4 (Lithium Iron Phosphate) |
| Cycle Life | 3,500+ cycles to 80%+ capacity |
| AC Output | 3600W continuous at 120V, bidirectional pure sine wave |
| Peak Power | 7000W surge |
| 240V Output | 7200W at 240V with two units and the 240V connect box |
| DC 12V Output | 12V/30A max |
| USB-C Output | 100W (multi-voltage) |
| USB-A Output | 18W max (4 ports) |
| Wireless Charging | 15W max (2 pads) |
| AC Input | 3200W with 30A cable, 1800W with 15A cable |
| Solar Input (XT60-M) | 2400W max (2 x 1200W), Voc 32V-150V, 20A max |
|---|---|
| Solar Input (DC5521) | Voc 12V-30V, 150W max, 7A max |
| Car Input | 12V-30V DC, 150W max, 7A max |
| AC Charging Time | 1.3 hours (30A), 2 hours (15A) |
| Expandable Capacity | Up to 18,432Wh with expansion batteries |
| Dimensions | L17.5in x W12.1in x H13.8in |
| Weight | Approximately 79 lbs (36 kg) |
| Charge Temperature | 32F to 113F (0C to 45C) |
| Discharge Temperature | -4F to 113F (-20C to 45C) |
| Warranty | 2+3 years |
3072Wh of LiFePO4 capacity behind a 3600W bidirectional inverter, expandable to 18,432Wh and capable of 240V output when two units are paired with the connect box.
Key Features
- 3600W Bidirectional Inverter - 7000W surge for hard-starting loads
- 240V Capable - Two units plus the 240V connect box deliver 7200W at 240V
- 3072Wh LiFePO4 Battery - Rated 3,500+ cycles to 80% capacity
- 2400W Solar Input - Dual XT60 inputs at 1200W each, 32V to 150V open circuit
- 1.3-Hour AC Charging - 3200W on a 30A cable, 1800W on standard 15A
- Expandable to 18,432Wh - Add expansion batteries for whole-home runtime
- Full Port Complement - 12V/30A DC, 100W USB-C, four USB-A, and two 15W wireless charging pads
- UPS Passthrough - Protects connected equipment through outages
Ideal For
- Whole-home and critical-circuit backup
- 240V well pumps, compressors, and shop equipment
- Off-grid cabins and extended remote stays
- Mobile command, film, and event power
- Large solar generator builds
Backed by a 2+3 year manufacturer warranty.
